OERTZEN High Pressure Cleaner E 320


  • Cold water high pressure cleaner with 3 cylinder inline plunger pump
    (brass pump head, ceramic plungers) - flanged to electric motor

  • motor/pump rpm 1420 1/min - slowly, quietly running machine

  • pump system pressureless by closing spray pistol (stand by operation)

  • thermo valve protects pump from overheating

  • water shortage control protects pump from cavitation

  • water micro filter protects pump from soiled water

  • motor/pump unit protected by solid, surrounding steel frame
    (powder coated)

  • chassis with 4 wheels on twin axle, locking brake

  • hose swivel prevents hp hose from messing up

  • Hot water module HOT BOX (see accessories) turns E 320 into hot water cleaner.





  Flow rate max. 1320 l/h
  Unloading pressure 330 bar
  Working pressure max. 310 bar
  Water temperature max. cold water
  Standard voltage 380V/3~50 Hz
  Pump speed 1420 1/min
  Power source electric motor
  Connecting power 12.5 kW
  Thermo valve serial
  Safety Control Stop (SCS) option
  Dimensions (LxWxH) 700 x 600 x 720 mm.
  Weight 112 kg.
